Product information

Carspa PX700-12 Voltage Inverter – pure sine wave inverters offer excellent quality and true sine wave output for powering your favourite tools and other sensitive loads.
The LCD display shows input data, output data and alarm notifications.

Product features:
- Pure sine wave output (THD <2%)
- LCD display shows operating and fault statuses (input voltage, output voltage, output power, battery capacity level, load level, interface code and fault code)
- High resistance to surge currents; capable of powering heavy loads such as televisions, motors and more.
- The inverter’s cooling fan is thermally activated; it switches off automatically once the inverter has cooled down.
- Earth fault protection
- Soft start: smooth start-up of appliances.
- Pure sine wave output: stable power for sensitive loads.
- Powerful microprocessor
- Environmentally friendly, non-flammable material
- Option to connect a remote control
- Manual switch: ON / OFF / Remote control

Protection functions:
- Reverse polarity protection
- Low voltage: on and off alarm
- Overvoltage protection
- Overload protection
- Thermal protection
- Short-circuit protection
- Reverse polarity protection
- Soft start
- Auto-reset
- Earth leakage protection

Technical specifications:
- Dimensions: 284 × 150 × 78 mm
- Weight: 0.5 kg
- 12V, 230V, 50Hz
- Output: 700W continuous, 1000W peak
- Pure sine wave
- Operating temperature: -20 to 50 °C
- Operating humidity: 20% – 90% RH, non-condensing

Connectors, sockets:
- Type F socket – Euro with earth pin
- USB socket – 5V 2.1 A, power supply for additional devices
- RJ45 socket – Option to connect a remote control
- GAB socket – Communication port; manufacturer’s specification is pending
- Terminal block – For connecting cables to the battery

Package contents:
Voltage converter
Battery connection cables
Spare fuses
